At the nanometer scale, the environment is not just a backdrop to the process. It is part of the process. A single particle, an electrostatic discharge event, or an outgassing compound from a wall panel can compromise an entire wafer run. CleanSpace designs and builds cleanroom environments where those variables are controlled from the panel level up, so your tools operate in conditions that protect yield from day one.
ESD Protection
Anti-static wall panels and conductive flooring systems that prevent electrostatic discharge from damaging sensitive wafers and components
Vibration Dampening
Structural design and material selection that manages floor and wall vibration for sensitive lithography and metrology equipment
Outgassing Control
Panel and finish materials specified to avoid chemical off-gassing that would contaminate process environments at the molecular level
HEPA and ULPA Filtration
High-efficiency air filtration systems designed to maintain ISO Class 5 and below particle counts across process bays
Temperature and Humidity Precision
Stable, tightly controlled thermal and humidity environments that protect process chemistry and tool calibration
Subfab Integration
Coordination of below-fab mechanical systems with process bay requirements for complete facility performance
Scalable Modular Labs for Emerging Technology R&D
The pace of innovation in AI hardware, quantum computing, photonics, and next-generation semiconductor nodes is outrunning traditional facility timelines. A research program can shift focus entirely between the time a conventional lab breaks ground and the time it opens. CleanSpace modular labs are designed to move with that pace. Walls reconfigure. Capacity scales. And because the system is modular from the start, a pilot R&D environment today can evolve into a production cleanroom tomorrow without tearing anything down.
Wafer Fabrication
ISO-classified process bay environments engineered for advanced node lithography and etch operations
Microelectronics Assembly
Particle and ESD controlled environments for chip packaging, wire bonding, and module assembly
AI and Advanced Compute Hardware
High-precision environments for next-generation processor and accelerator fabrication
Photonics and Optical Components
Ultra-low particle environments for laser, fiber optic, and sensor manufacturing
Quantum Computing Research
Vibration-isolated, temperature-stable environments for qubit fabrication and cryogenic system integration
Semiconductor R&D Labs
Flexible, scalable modular environments that evolve with your research program
Integrated MEP Systems for Precise Climate and Particle Control
CleanSpace also recognizes that cleanrooms are among the most energy-intensive components of a semiconductor facility. Through optimized airflow strategies, efficient system design, and intelligent environmental control, CleanSpace helps reduce energy consumption while maintaining the strict performance standards required for advanced fabrication. With vertically integrated capabilities and experienced installation teams, the result is a high-performance environment that supports tooling, protects process integrity, and improves long-term operational efficiency.
Speed to Production Before Your Technology Window Closes
Semiconductor technology moves faster than any other industry. A six-month construction delay is not just a cost overrun; it can make a product line obsolete before it ever runs a wafer. CleanSpace's CleanFit process compresses design to installation into weeks rather than months, with parallel off-site fabrication that keeps your critical path tight. And because every system is 100% manufactured in the USA, your fab build is not sitting in an overseas queue while your competitors move forward.
